Description
Key Features
1. High-Volume Vacuum Performance
The OPX-209 is designed for applications requiring a substantial vacuum pumping capacity and continuous operation.
2. Oil-Sealed Pump Design
The oil-sealed construction helps provide effective vacuum generation and supports stable operation during prolonged use.
3. Heavy-Duty Electric Motor
A heavy-duty electric motor is fitted to provide dependable power for continuous pump operation.
4. V-Belt Drive System
The pump uses a V-belt drive mechanism with an operating pump speed of approximately 400 RPM. The belt-driven arrangement allows the pump and motor to operate through a robust mechanical transmission system.
5. High-Grade Cast Iron Construction
The main pump construction uses high-grade cast iron, providing mechanical strength and durability for demanding operating environments.
6. Precision Machining
Critical pump components are precision-machined to micron-level accuracy, helping maintain close tolerances and support sustained vacuum performance.
7. Heavy Steel Base
The complete pump assembly is mounted on a heavy steel base plate to provide a stable foundation during operation.
8. Belt Guard for Safety
A protective belt guard is supplied as standard to cover the rotating belt and pulley assembly and improve operator safety.
Technical Specifications
| Specification | OPX-209 |
|---|---|
| Product Name | Single Stage Vacuum Pump |
| Model No. | OPX-209 |
| Pump Type | Oil-Sealed Vacuum Pump |
| Configuration | Single Stage |
| Pump Range | High Volume Range |
| Drive Type | V-Belt Drive |
| Pump Speed | Approx. 400 RPM |
| Motor | Heavy-Duty Electric Motor |
| Construction | High-Grade Cast Iron |
| Machining | Precision Machined |
| Base | Heavy Steel Base Plate |
| Safety Protection | Belt Guard |
| Lubrication | Oil Sealed |
| Power Supply | 220/230 V AC |
| Operation | Continuous Vacuum Pumping |
| Stage Options | Single Stage; Double Stage available in the range |
Specification note: Exact motor power, vacuum level, displacement/capacity, ultimate vacuum, inlet size, oil capacity, dimensions, and weight were not provided, so they should be added only from the manufacturer’s actual datasheet rather than estimated.
Working Principle
The OPX-209 Single Stage Vacuum Pump uses an oil-sealed pumping mechanism to remove air and other gases from a connected system.
The heavy-duty motor transfers rotational power through the V-belt drive to the pump. The pump operates at approximately 400 RPM, creating a pressure differential that draws gases from the connected vacuum system and discharges them through the pump outlet.
The oil-sealed design assists in maintaining effective sealing between internal moving components and supports stable vacuum generation.
Applications
The Single Stage Vacuum Pump OPX-209 can be used for:
- Laboratory vacuum systems
- Vacuum filtration
- Vacuum drying
- Laboratory evaporation systems
- Rotary evaporation systems
- Vacuum ovens
- Chemical laboratories
- Pharmaceutical laboratories
- Research laboratories
- Industrial vacuum applications
- Process equipment
- Vacuum distillation
- Degassing applications
- General-purpose vacuum generation
Advantages of OPX-209
- High-volume vacuum pumping capability
- Oil-sealed pump construction
- Heavy-duty electric motor
- Robust V-belt drive
- Approximately 400 RPM operating speed
- High-grade cast iron construction
- Precision-machined components
- Heavy steel mounting base
- Standard belt guard
- Designed for sustained vacuum operation
- 220/230 V AC power compatibility
- Suitable for laboratory and industrial applications
