Description

Technical Specifications

Speed & Control

• Speed Range: 100–2000 rpm
• Speed Control Accuracy: ±5%
• Display: LCD
• Display Information: Set speed and actual speed
• Timing Range: 1–99 h 59 min
• Programming: Multi-segment programming control
• Parameter Memory: Automatic memorization of final set working parameters

Motor & Performance

• Motor: DC Permanent Magnet Motor
• Operation: Low-noise and stable
• Maximum Torque: Up to 30 N·cm
• Maximum Stirring Volume: Up to 60 L H₂O
• Recommended Mixing Amount: Up to 15 L H₂O
• Maximum Stirrer Viscosity: Up to 30,000 mPa·s

Electrical

• Input Voltage: AC 100–240 V
• Frequency: 50–60 Hz
• Specified Operating Supply: 230 ±10 V / 50 Hz

Model Selection Guide

OPX-254-60

The highest-capacity configuration, offering 60 L maximum stirring volume, 30 N·cm maximum torque, and handling viscosity up to 30,000 mPa·s. Suitable for larger-volume and higher-viscosity laboratory mixing requirements.

OPX-254-40

Provides a 40 L maximum stirring volume, 20 N·cm torque, and viscosity handling up to 20,000 mPa·s. Suitable for medium-volume mixing applications.

OPX-254-20

Designed for smaller laboratory batches, with 20 L maximum stirring volume, 10 N·cm torque, and viscosity handling up to 10,000 mPa·s.

Available Models

Key Features

1. LCD Speed Display

The integrated LCD screen displays both:

• Set speed
• Actual speed

This provides clear monitoring of the stirring process and allows users to observe operating conditions conveniently.

2. DC Permanent Magnet Motor

The OPX-254 uses a DC permanent magnet motor designed for:

• Low-noise operation
• Stable performance
• Reliable continuous operation
• Reduced maintenance requirements

3. Automatic Safety Stop

The overhead stirring system is designed with an automatic stop function to help enhance operational safety and protect the equipment during abnormal operating conditions.

4. Stable Start-Up

Controlled start-up helps gradually accelerate the stirring operation, reducing sudden movement and helping to minimize sample overflow or splashing, particularly when working with larger volumes.

5. Parameter Memory

The instrument can automatically memorize the final set working parameters, allowing convenient continuation of routine operations without repeatedly entering the same settings.

6. Multi-Segment Programming

The OPX-254 supports multi-segment programming control, allowing users to establish different operating conditions within a programmed mixing process.

This is useful when an application requires different stirring speeds or operating stages.

7. Wide Speed Range

The stirring speed can be adjusted from 100 to 2000 rpm, providing flexibility for low-speed mixing as well as higher-speed applications.

8. High Torque Performance

Depending on the selected model, maximum torque is available up to 30 N·cm, allowing the instrument to handle progressively higher-viscosity materials.

Applications

The Overhead Stirrer OPX-254 can be used for:

• Chemical solution preparation
• Pharmaceutical formulation
• Laboratory sample preparation
• Biotechnology research
• Food and beverage research
• Cosmetic formulation
• Paint and coating research
• Polymer and resin mixing
• Suspension preparation
• High-viscosity liquid mixing
• Homogenization and blending
• Research and development laboratories
• Quality-control laboratories
• Educational and industrial laboratories

Advantages of OPX-254

• LCD display for set and actual speed
• 100–2000 rpm adjustable speed range
• DC permanent magnet motor
• Low-noise operation
• Stable stirring performance
• Up to 30 N·cm maximum torque
• Maximum stirring capacity up to 60 L H₂O
• Multi-segment programming
• Automatic parameter memory
• Long-duration timer up to 99 h 59 min
• Controlled start-up to reduce sample overflow
• Automatic safety stop function
• Multiple capacity configurations
• Suitable for higher-viscosity samples
