Description
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | OPXICA Advance Polarizing Binocular Microscope APBM-138 |
| Model Number | APBM-138 |
| Microscope Type | Polarizing Binocular Microscope |
| Observation Head | Binocular Head |
| Optional Head | Monocular & Trinocular Compatible |
| Eyepiece | Paired Eyepieces 5X (Cross), 10X (Ocular), Optional 15X |
| Objective Lenses | P5X, P10X, P40X, P45X |
| Polarizing System | Bertrand Lens with Sliding Analyzer |
| Wave Compensator | λ and 1/4 λ Wave Plate |
| Stage Type | 360° Rotatable Circular Stage |
| Stage Graduation | 0–360° Vernier Scale |
| Focusing System | Co-Axial Coarse & Fine Focusing |
| Condenser | Adjustable Condenser N.A. 1.25 |
| Illumination Type | Incident & Transmitted Illumination |
| Light Source | Dual Illumination System |
| Application | Crystal, Mineral & Material Analysis |
| Brand | OPXICA |
Key Features
Advanced Polarizing Optical System
The Advance Polarizing Binocular Microscope features a high-quality polarizing system that enables detailed examination of birefringent and anisotropic materials.
Bertrand Lens Integration
Equipped with a Bertrand lens and sliding analyzer for accurate interference pattern observation and crystal structure analysis.
Dual Illumination Technology
Provides both transmitted and incident illumination, allowing examination of transparent and opaque specimens.
360° Rotatable Circular Stage
Precision circular stage with vernier scale enables accurate angular measurements during mineral and crystal studies.
Multiple Objective Magnifications
Includes specialized polarizing objectives for high-resolution observation and material characterization.
Precision Co-Axial Focusing
Smooth coarse and fine focusing controls ensure sharp image clarity and accurate specimen positioning.
Expandable Observation System
Supports binocular viewing with optional monocular and trinocular configurations for imaging and documentation.
Heavy-Duty Laboratory Construction
Built with durable materials to withstand continuous use in research laboratories and educational institutions.
Working Purpose
The Advance Polarizing Binocular Microscope is specifically designed to analyze optical properties of materials that interact with polarized light. It is widely used for:
- Mineral identification and classification
- Crystal structure examination
- Geological and petrographic analysis
- Rock thin section studies
- Material science investigations
- Polymer and fiber analysis
- Quality control of industrial materials
- Research and educational applications
- Optical property determination of anisotropic specimens
- Gemstone and crystal examination
Applications
- Geological Laboratories
- Petrographic Research Centers
- Mineralogy Laboratories
- Universities and Colleges
- Material Science Research Facilities
- Mining Industry Laboratories
- Ceramic and Glass Industries
- Gemological Institutes
- Industrial Quality Control Departments
- Scientific Research Organizations
Conclusion
The Advance Polarizing Binocular Microscope APBM-138 is a powerful analytical instrument developed for advanced crystal, mineral, and material investigations. Combining a Bertrand lens, sliding analyzer, precision rotating stage, and dual illumination system, it provides outstanding accuracy and optical performance. The Advance Polarizing Binocular Microscope is an excellent choice for geologists, mineralogists, researchers, educators, and industrial professionals seeking dependable results in polarizing microscopy applications. With OPXICA’s commitment to quality and innovation, the APBM-138 delivers reliable performance for modern scientific and industrial laboratories.
