Description
Model Number: OPX-302
The OPXICA OPX-302 Digital Laboratory Centrifuge is a microprocessor-controlled benchtop centrifuge designed for efficient separation of serum from blood, PCV procedures, cytology tests, and routine laboratory applications. It combines programmable speed control, digital timing, a brushless motor, swing-out rotor, and anti-vibration construction for smooth and dependable operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | OPX-302 |
| Product Name | Digital Centrifuge / Laboratory Centrifuge |
| Brand Name | OPXICA |
| Type | Benchtop Digital Centrifuge |
| Maximum Speed | 2850 RPM |
| Maximum RCF | 1325 × g |
| Speed Range | 500–2850 RPM |
| Speed Setting Interval | 250 RPM |
| Speed Controller | Microprocessor-Based Pre-Programmable Controller |
| Rotor Type | Swing-Out Rotor |
| Motor | Brushless Motor |
| Timer Range | 1–99 Minutes |
| Timer Setting Interval | 1 Minute |
| Display | Large Digital Display |
| Display Parameters | RPM, RCF, Set Time & Run Time |
| Parameter Memory | Last Test Parameter Recall |
| End-of-Cycle Alert | Beep Sound |
| Anti-Vibration System | Motor Mounted on Anti-Vibration Pads |
| Body Construction | Heavy-Duty C.R.C. Construction |
| Surface Finish | Powder-Coated Finish |
| Power Supply | 230V ±10%, 50Hz |
| Applications | Serum Separation, Blood Testing, PCV & Cytology Tests |
Key Features
- Maximum speed of 2850 RPM
- Maximum RCF of 1325 × g
- Microprocessor-based programmable speed control
- Adjustable speed from 500 to 2850 RPM
- Speed adjustment in intervals of 250 RPM
- Digital timer adjustable from 1 to 99 minutes
- Timer adjustment in 1-minute intervals
- Large digital display for RPM, RCF, set time, and run time
- Automatic recall and display of the last test parameters
- Brushless motor for dependable laboratory operation
- Swing-out rotor configuration
- Anti-vibration pads help provide stable operation
- Heavy-duty C.R.C. body construction
- Durable powder-coated finish
- Audible beep at the completion of the set cycle
- Designed as a compact benchtop laboratory centrifuge
- Suitable for routine clinical and laboratory applications
Advanced Microprocessor Control
The OPX-302 Digital Centrifuge features a microprocessor-based pre-programmable controller that allows users to select operating speeds between 500 and 2850 RPM in increments of 250 RPM. This digital control system enables convenient adjustment of operating parameters according to the laboratory procedure.
The unit also recalls the last test parameters, which are automatically displayed for convenient repeat operation.
Digital Display & Timer
The centrifuge incorporates a large digital display for monitoring important operating parameters, including RPM, RCF, set time, and run time.
Its digital timer can be programmed from 1 to 99 minutes in one-minute increments. At the completion of the selected operating time, an audible beep alerts the operator that the cycle has finished.
Stable & Low-Vibration Operation
For improved operational stability, the motor is mounted on anti-vibration pads, helping minimize vibration and unwanted movement during centrifugation.
The combination of a brushless motor, robust construction, and balanced swing-out rotor configuration makes the OPX-302 suitable for regular laboratory use.
Heavy-Duty Construction
The OPX-302 is manufactured with a heavy-duty C.R.C. construction and finished with a durable powder-coated surface. Its benchtop configuration is designed to provide a practical combination of strength, stability, and convenient laboratory placement.
Working Purpose
The OPXICA OPX-302 Digital Laboratory Centrifuge is designed to separate components of samples through centrifugal force. It is particularly suitable for separation of serum from blood, PCV procedures, cytology tests, and other compatible laboratory centrifugation applications.
Its adjustable speed, programmable timer, digital parameter display, and swing-out rotor provide convenient control for routine laboratory workflows.
Applications
The OPX-302 is suitable for:
- Serum separation from blood
- PCV procedures
- Cytology tests
- Clinical laboratory applications
- Pathology laboratories
- Diagnostic laboratories
- Hospital laboratories
- Medical colleges and institutions
- Research laboratories
- Educational laboratories
- Routine sample separation
Supplied Accessories
The centrifuge is supplied with an instruction manual, power cord and plug, head puller, dust cover, and spanner for removal of the rotor head, supporting convenient installation, operation, and routine handling.
At the End
The OPXICA OPX-302 Digital Centrifuge provides a practical solution for laboratories requiring controlled and efficient sample separation. With a maximum speed of 2850 RPM, maximum RCF of 1325 × g, microprocessor-based controls, digital timing, parameter recall, and a brushless motor, it supports convenient routine laboratory operation.
Its heavy-duty construction, anti-vibration arrangement, swing-out rotor, and digital display make the OPX-302 suitable for pathology laboratories, diagnostic centers, hospitals, medical institutions, research facilities, and other laboratory environments.
Frequently Asked Questions (FAQs)
1. What is the OPXICA OPX-302 Digital Centrifuge used for?
The OPX-302 is designed for laboratory centrifugation applications including serum separation from blood, PCV procedures, cytology tests, and other compatible routine sample-separation processes.
2. What is the maximum speed of the OPX-302?
The centrifuge provides a maximum speed of 2850 RPM.
3. What is the maximum RCF?
The maximum Relative Centrifugal Force (RCF) is 1325 × g.
4. What is the adjustable speed range?
The speed can be controlled from 500 to 2850 RPM in intervals of 250 RPM.
5. Does the OPX-302 have a digital speed controller?
Yes. It features a microprocessor-based pre-programmable speed controller for setting and controlling the operating speed.
6. What type of motor is used?
The OPX-302 is fitted with a brushless motor, designed for dependable laboratory operation.
7. What type of rotor does the centrifuge use?
It is equipped with a swing-out rotor.
8. Does the centrifuge have a digital timer?
Yes. The timer can be set from 1 to 99 minutes in one-minute intervals.
9. Which parameters are shown on the display?
The display provides information for RPM, RCF, set time, and run time.
10. Does it remember the previous test settings?
Yes. The OPX-302 features last test parameter recall, allowing the previous parameters to be displayed automatically.
11. Does the centrifuge provide an alert when the cycle finishes?
Yes. An audible beep sound indicates when the selected operating time has been completed.
12. How is vibration controlled?
The motor is mounted on anti-vibration pads to help minimize vibration and displacement during operation.
13. What is the body made from?
The centrifuge features heavy-duty C.R.C. construction with a powder-coated finish for durability.
14. Is the OPX-302 suitable for blood serum separation?
Yes. One of its specified applications is the separation of serum from blood.
15. Can it be used for PCV applications?
Yes. The OPX-302 is designed for PCV and compatible laboratory centrifugation procedures.
16. Is the OPX-302 suitable for cytology laboratories?
Yes. Cytology testing is among the specified applications of this centrifuge.
17. What power supply does the centrifuge require?
The unit operates on a 230V ±10%, 50Hz power supply.
18. What accessories are supplied with the OPX-302?
It is supplied with an instruction manual, cord and plug, head puller, dust cover, and spanner for removing the rotor head.
19. Where can the OPX-302 be used?
It is suitable for pathology laboratories, diagnostic laboratories, hospitals, research facilities, medical institutions, educational laboratories, and other compatible laboratory environments.
20. Why choose the OPXICA OPX-302 Digital Laboratory Centrifuge?
The OPX-302 combines microprocessor-based control, programmable speed, digital timing, parameter recall, a brushless motor, swing-out rotor, anti-vibration construction, and a durable body, making it a practical option for routine laboratory centrifugation.
