Description
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Fluorescence Microscope FM-110 |
| Brand | OPXICA |
| Microscope Type | Inverted Fluorescence Microscope |
| Optical System | Infinity Corrected Optical System |
| Observation Modes | Bright Field, Phase Contrast, Fluorescence & DIC |
| Viewing Head | Binocular Siedentopf Head, 35° Inclined |
| Camera Port | Integrated Trinocular Camera Port |
| Eyepieces | WF 10X / 22 mm High Eyepoint |
| Interpupillary Distance | 50–75 mm |
| Nosepiece | Six Position Revolving Nosepiece |
| Objectives | Long Working Distance Objectives (10X, 20X, 40X, 60X) |
| Condenser | Universal Turret Condenser |
| Mechanical Stage | 250 × 160 mm Precision Mechanical XY Stage |
| Stage Travel | 114 mm × 73 mm |
| Focusing | Coaxial Coarse & Fine Focus |
| Illumination | High Intensity Scientific White LED |
| Fluorescence System | Four Position LED Fluorescence Filter Turret |
| Fluorescence Filters | DAPI, FITC, TRITC, CY5 |
| Camera | 25 MP Scientific CMOS Camera |
| Image Resolution | 4800 × 3600 Pixels |
| Frame Rate | Up to 60 fps |
| Connectivity | USB 3.2 Gen2, HDMI & Wi-Fi |
| Software | Imaging, Measurement, Time-lapse, Z-Stack & AI Analysis |
| Computer | Intel i7 Workstation, 8 GB RAM, 1 TB SSD |
| Operating System | Windows 10 / Windows 11 |
| Accessories | Dust Cover, Filters, Instruction Manual |
Key Features
- Infinity Corrected Optical System
- Advanced Inverted Fluorescence Microscope
- Bright Field, Phase Contrast, DIC & Fluorescence Observation
- Scientific Grade High Intensity LED Illumination
- Integrated Camera Port for Digital Imaging
- Six Position Revolving Nosepiece
- Long Working Distance Objectives
- Universal Turret Condenser
- Large Precision Mechanical XY Stage
- Precision Coaxial Coarse & Fine Focusing
- Four Position Fluorescence Filter Turret
- DAPI, FITC, TRITC & CY5 Filter Sets
- 25 MP Scientific CMOS Camera
- USB 3.2, HDMI & Wi-Fi Connectivity
- Professional Imaging & Measurement Software
- Time-Lapse, Z-Stack & Image Stitching
- AI-Assisted Image Analysis
- Ergonomic Laboratory Design
- Suitable for Live Cell Imaging
- Ideal for Research & Clinical Laboratories
Working Purpose
The OPXICA Fluorescence Microscope FM-110 is developed for high-resolution fluorescence imaging and live cell observation. It allows researchers to study fluorescently labeled cells, microorganisms, tissues, and biological samples with exceptional clarity. The microscope is widely used for cancer research, immunofluorescence, stem cell research, molecular biology, microbiology, pathology, IVF research, pharmaceutical development, and biomedical sciences.
Applications
- Cell Biology Research
- Molecular Biology
- Cancer Research
- Immunofluorescence Studies
- Microbiology Laboratories
- Histopathology
- Clinical Diagnostics
- IVF Laboratories
- Pharmaceutical Research
- Biotechnology Industries
- Medical Universities
- Research Institutes
- Hospitals
- Drug Discovery Laboratories
- Life Science Research
Frequently Asked Questions (FAQs)
1. What is the OPXICA Fluorescence Microscope FM-110 used for?
It is used for fluorescence imaging, live cell observation, molecular biology, microbiology, pathology, cancer research, and biomedical applications.
2. Which observation methods are supported?
The FM-110 supports Bright Field, Phase Contrast, Differential Interference Contrast (DIC), and Fluorescence observation.
3. What optical system does the microscope use?
It features an Infinity Corrected Optical System for superior image quality and optical performance.
4. Which fluorescence filters are included?
The microscope supports DAPI, FITC, TRITC, and CY5 fluorescence filter cubes.
5. What camera is supplied with the microscope?
It includes a 25 MP Scientific CMOS Digital Camera with USB 3.2, HDMI, and Wi-Fi connectivity.
6. Is the microscope suitable for live cell imaging?
Yes. The FM-110 supports live cell imaging and can be expanded with an on-stage incubator for long-term observation.
7. Does the microscope support image analysis software?
Yes. It includes professional software for image acquisition, measurement, Z-stack imaging, time-lapse recording, image stitching, annotation, and AI-assisted analysis.
8. Can this microscope be used in pharmaceutical and biotechnology laboratories?
Yes. It is ideal for pharmaceutical research, biotechnology laboratories, life science research, and clinical diagnostics.
9. What objectives are included?
The microscope is equipped with Long Working Distance (LWD) objectives of 10X, 20X, 40X, and 60X, optimized for bright field, phase contrast, and fluorescence imaging.
10. Why choose the OPXICA Fluorescence Microscope FM-110?
The FM-110 combines advanced fluorescence imaging, precision optics, scientific-grade illumination, a high-resolution CMOS camera, and powerful imaging software, making it a dependable solution for advanced biomedical research, diagnostics, and life science applications.
